Pressure Rating: 3000 to 6000 psi
Material: Seamless Tube, AISI 1026
Valve Ports: 1" NPT on 16" Centers
End Ports: 1" NPT
Bleed Port: 1/2" NPT 90° from Valve Port
Top (Bypass) Port: 1" NPT
Gauge Port: 1/4" NPT on center with Bleed Port
Case Styles Provide: 2-1/2" (63MM) 4" (100MM) 6” (160MM)1/4" NPT Port Size
SV-25 Repair Kit Contents: O-ring Kit; O-rings and backup rings Seal Kit; includes O-ring Kit and seal rings Minor Repair Kit; includes Seal Kit and rotor Major Repair Kit; includes Minor Repair Kit, thrust washers and balls
SV-50 Repair Kit Contents: O-ring Kit; O-rings and backup rings Seal Kit; includes O-ring Kit and seal rings Minor Repair Kit; includes Seal Kit and rotor Major Repair Kit; includes Minor Repair Kit, thrust washers and balls
SV-100 Repair Kit Contents: O-ring Kit; O-rings and backup rings Seal Kit; includes O-ring Kit and seal rings Minor Repair Kit; includes Seal Kit and rotor Major Repair Kit; includes Minor Repair Kit, thrust washers and balls
SV-150 Repair Kit Contents: O-ring Kit; O-rings and backup rings Seal Kit; includes O-ring Kit and seal rings Minor Repair Kit; includes Seal Kit and rotor Major Repair Kit; includes Minor Repair Kit, thrust washers and balls
Pressure Rating: 6000 psiMaterial: Seamless Tube, AISI 1026 Bottle Ports:1¼" NPT on 12" Centers End Ports: 2" NPT
